SPECIFICATION

System:

Working range: above 60 meters (visual range)

Audio response: 20 Hz-18 kHz

Total harmonic distortion: <1%(@AF1 KHz, RF46 dBu)

Audio dynamic range: ≥106 dB

S/N Ratio: >90 dB

Pilot frequency: 30.000KHz

Receiver:

Audio output level: Unbalanced +9dBu/ Balanced +9dBu

Audio output impedance: unbalanced 810 Ohms/ Balanced 240 Ohms

Sensitivity: <-105 dBm (12 dB sinad)

Image suppression: >50 dB

Power supply voltage: 12~15V

Handheld transmitter:

Mic capsule: 600Ω cardioid dynamic capsule

Input gain range: 20 db

RF output power: <10 dbm

Operating voltage: 3V (2*AA&R6)

Battery life: 6 Hours
