Product features：

※ Use in a variety of environments, such as news interview, mobile  recording, sound engineer debugging system.

※ Adopt full color LCD screen to display the function data .

※ High, medium and low power selection, adapt to different use  requirements.

※ With operation lock function to prevent mis-operation.

※ Have non-interference frequency can be set and change, more units  working together without interference .

※ UHF band, PLL frequency synthesis technology.

※ 9 level audio gain adjustment, can be adjusted according to the performance environment.

※ Metal case, built-in transmitting antenna design, so that the  appearance design is compact and beautiful.

※ This product can be real-time charging, also can be quickly replaced  18500 lithium battery

SPECIFICATION：

System

Working range: 100 meters

AF response : 20Hz -18KHz

T. H.D : <1%(AF 1KHz , RF46dBu)

Dynamice Range : >100dBA

S / N ratio : >90dB

Pilot frequency : 32.768KHz

Transmitter

Modulation :  FM

Band width :  60MHz

Frequency stability :  ± 0.005%

Frequency range :   470-960MHz

Oscillation Mode :   PLL

Maximum deviation :  ±75KHz

Harmonic radiation :   lower than main wave above 45dBm

AF compress :   AF compress circuit

Pilot frequency :   32.768KHz

Input connector :  XLR

Input impedance :   1MΩ

Input phantom power :   48V

Input gain range:   30dB

RF output power :   1mW/10mW

Current consumption :   180mA (maximum)

Power supply :   3.7V 18500 lithium battery

Working hour :   8 hours

Dimension :   120*40*40
